130BF088.10
1
2
3
4
5
6
7
8
9
10
1 DC fuse and microswitch 6 AC input busbars
2 44-pin connector for cable from MDCIC 7 AC fuses
3 Blank cover plate (no LCP) 8 Mains terminals to drive module
4 Blank mounting plate (no control card) 9 Mixing fan
5 Power card 10 Output terminals to motor
Illustration 12.7 Parallel Drive Module
Da2/Db2/Da4/Db4 Parallel Sy...
VLT
®
FC Series, D1h–D8h, Da2/Db2/Da4/Db4, E1h–E4h, J8/J9
256 Danfoss A/S © 02/2019 All rights reserved. MG94A502
