Danfoss Metasys N2 Service Guide

130BF766.10
1
2
3
5
6
7
9
10
4
8
1 Inrush card frame 6 Bus plate screw (T40)
2 Nut (7 mm) 7 Insulator sheet
3 Inrush busbars 8 Insulator sheet alignment pin
4 Nut (7 mm) 9 Rectier(+) bus plate
5 Rectier(-) bus plate 10 Bus plate screw (T40)
Illustration 13.6 Inrush Card Frame and Rectier Bus Plates
E1h–E4h Drive Disassembly a...
VLT
®
FC Series, D1h–D8h, Da2/Db2/Da4/Db4, E1h–E4h, J8/J9
272 Danfoss A/S © 02/2019 All rights reserved. MG94A502
1313
