1 DC capacitor bank 9 Heat sink fan housing
2 Fan cutout 10 Hole for fan grommet
3 Nut (13 mm) 11 IGBT output busbar
4 Current sensor busbar 12 Right motor busbar
5 Nut (8 mm) 13 Nut (13 mm)
6 Current sensor 14 Fan grommet
7 Fan grommet (installed in fan housing) 15 Heat sink fan
8 Fan cable heat sink fan 16 Fan cable connector
Illustration 13.17 Heat Sink Fan (Shown with Left Motor Busbar Removed)
E1h–E4h Drive Disassembly a...
VLT
®
FC Series, D1h–D8h, Da2/Db2/Da4/Db4, E1h–E4h, J8/J9
294 Danfoss A/S © 02/2019 All rights reserved. MG94A502
