3 Appendix
3.1.1 Analog Inputs (AI)
NPA Unit Description Range FC Par. Number
0 % Reference [%] - 16-02
1 - Reference [Unit] - 16-01
2 - Feedback - 16-52
3 Hz Frequency - 16-13
4 - User defined readout - 16-09
5 A Current - 16-14
6 kW Power - 16-10
7 hp Power - 16-11
8 V Output Voltage - 16-12
9 V DC Voltage - 16-30
10 % Motor Thermal Protection - 16-18
11 % Inverter Thermal Protection - 16-35
12 V Terminal 53 analog - 16-62
13 V Terminal 54 analog - 16-64
16 % External reference - 16-50
17 C Heat sink temperature - 16-34
18 Hour Operating hours - 15-00
19 Hour Running hours - 15-01
20 kWh kWh counter - 15-02
21 - Power-ups - 15-03
22 - Over temps - 15-04
23 - Over voltages - 15-05
24 - Start Ups - 15-08
25 - Torque [%] - 16-22
26 - Speed [rpm] - 16-17
27 - Analog Input, GPIO X30/11 - 16-75
28 - Analog Input, GPIO X30/12 - 16-76
29 - Analog Input, IO option X42/1 -20.000 to +20.000 18-20
30 - Analog Input, IO optionX42/3 -20.000 to +20.000 18-21
31 - Analog Input, IO optionX42/5 -20.000 to +20.000 18-22
32 - Analog Out X42/7 - 18-33
33 - Analog Out X42/9 - 18-34
34 - Analog Out X42/11 - 18-35
40 - ECB: Bypass Running Hours
0-2
32
/10
31-11
45 - Feedback 1 [Unit] - 16-54
46 - Feedback 2 [Unit] - 16-55
47 - Feedback 3 [Unit] - 16-56
48 - Ext. 1 Feedback [Unit] - 21-18
49 - Ext. 2 Feedback [Unit] - 21-38
The default values are shown in bold on the following pages. Any point not listed on the following pages is reserved for future
use.
Some Metasys software uses an object number range from 0 to 255, other Metasys software uses the range 1 to 254. The latter
software will interpret object number 0 as 1, and 1 as 2, etc. To access the proper point with this Metasys software, add 1 to the
NPA number in the tables.
