Danfoss Metasys N2 - Binary Inputs (BI)

3.1.2 Binary Inputs (BI)
NPA Unit Description Range FC Par. Number
0 15 Timers Status 0=OK, 1=Limit
Par. 16-03 Status Word
1 14 Current Status 0=OK, 1=Limit
2 13 Voltage Status 0=OK, 1=Limit
3 12 Inverter Status 0=OK, 1 =Stall, Auto-start
4 11 Running Status 0=Not Running, 1=Running
5 10 Frequency Status 0=Out of Range, 1=In Range
6 9 Control Status 0=Local, 1= Bus
7 8 Reference Status 0=Not on Ref., 1=On Ref.
8 7 Warning Status 0=No Warning , 1= Warning
9 3 Tripped Status 0=No Trip , 1=Tripped
10 2 Drive Enabled Status 0=Not Enabled , 1=Enabled
11 1 Drive Ready Status 0=Not Ready, 1=Ready
12 0 Drive Controller Status 0=Not Ready, 1=Ready
16 31 Reserved
Par. 16-92 Warning Word
17 30 Reserved
18 29 Unused
19 28 Unused
20 27 Voltage Limit 0=OK, 1=Warning
21 26 Low Temperature 0=OK, 1=Warning
22 25 Current Limit 0=OK, 1=Warning
23 24 Mains Failure 0=OK, 1=Warning
24 23 24V Supply Low 0=OK, 1=Warning
25 22 Fieldbus Fault 0=OK, 1=Warning
26 21 Speed Limit 0=OK, 1=Warning
27 20 Brake IGBT 0=OK, 1=Warning
28 19 Brake Resistor 0=OK , 1=Warning
29 18 Brake Overload 0=OK, 1=Warning
30 17 10V low 0=OK, 1=Warning
31 16 Live Zero Error 0=OK, 1=Warning
32 15 No Motor 0=OK, 1=Warning
33 14 Mains Phase Loss 0=OK, 1=Warning
34 13 DC Voltage High 0=OK, 1=Warning
35 12 DC Voltage Low 0=OK, 1=Warning
36 11 DC Overvoltage 0=OK, 1=Warning
37 10 DC Undervoltage 0=OK, 1=Warning
38 9 Inverter Overload 0=OK, 1=Warning
39 8 Motor ETR Overload 0=OK, 1=Warning
40 7
Motor Thermal
Overload
0=OK, 1=Warning
41 6 Torque Limit 0=OK, 1=Warning
42 5 Over Current 0=OK, 1=Warning
43 4 Ctrl. Word Timeout 0=OK, 1=Warning
44 3 Ctrl. Card Temp. 0=OK, 1=Warning
45 2 Earth Fault 0=OK, 1=Warning
46 1 Pwr. Card Temp 0=OK,1=Warning
47 0 Brake Check 0=OK1=Warning
