2.1.8 Analog Input Commands (Not Acknowledged)
VLT
Response
Comm and Region NPA Object no. Attribute
No.
Attribute Message Type Error
Code
Comments
NAK 1 1 0-23 4 Float Read Analog
Input
11
1 )
Read Linear Ranging Parameter 1
attribute associated with each
individual point. (JCI use only)
NAK 1 1 0-23 5 Float Read Analog
Input
11
1)
Read Linear Ranging Parameter 2
attribute associated with each
individual point. (JCI use only)
NAK 2 - 0-23 2 Byte Write Analog
Input
11
1)
Object Status writeable
NAK 2 - 0-23 3 Float Write Analog
Input
11
1)
Analog Input Value not writeable
NAK 2 - 0-23 4 Float Write Analog
Input
11
1)
Write to Linear Ranging Parame-
ter 1 attribute associated with
each individual point. (JCI use
only)
NAK 2 - 0-23 5 Float Write Analog
Input
11
1)
Write to Linear Ranging Parame-
ter 2 attribute associated with
each individual point. (JCI use
only)
NAK 2 - 0-23 6 Float Write Analog
Input
11
1)
Write to Linear Ranging Parame-
ter 3 attribute associated with
each individual point. (JCI use
only)
NAK 2 - 0-23 7 Float Write Analog
Input
11
1)
Write to Linear Ranging Parame-
ter 4 attribute associated with
each individual point. (JCI use
only)
NAK 2 - 0-23 13 Integer Write Analog
Input
11
1)
Write to Filter Weight attribute
associated with each individual
point. (JCI use only)
NAK 2 - 0-23 14 Float Write Analog
Input
11
1)
Write to AI Offset attribute associ-
ated with each individual point.
(JCI use only)
1)
Error code 11 is used because attributes are considered as fields/records in the point map database.
