Dimensions
SM/SZ 148-161
Grommet
All dimensions in inch
Ø 10.47
7.32
7.79
17.33
7.87
3.92
6.24
4 holes
Ø 0.76
6.8
8.66
8.66
11.18
14.08
8.23
11.18
SM 148-161 code 3 SM 148-161 code 4
30°
23.27
7.09
14.79
4.54
10.65
Ø10.47
3.92
17.33
7.36
13.03
3.89
HM 8 bolt
Lock washer
Flat washer
Steel mounting sleeve
Rubber grommet
Nut
1.10 inch
Compressor
base plate
11
FRCC.PC.003.A5.22
Application guidelines
