Ordering information & packaging
Packaging
Danfoss scroll compressors may be ordered
from Danfoss Commercial Compressors in either
industrial packs or in single packs as listed in
following tables For tandem assemblies, please
refer to the Danfoss parallel application guideline
reference FRCC.PC.005.
Ordering information
R22
R22
SM112-124-147 compressors in industrial pack
SM112-124-147 compressors in single pack
Compressor models
Single pack Industrial pack
Length
in
Width
in
Height
in
Gross
weight
lb
Nbr*
Length
in
Width
in
Height
in
Gross
weight
lb
Static
stacking
pallets
SM/SZ084 18.5 14.6 23.5 148 8 44.9 37.4 27.8 1213 3
SM/SZ090 18.5 14.6 23.5 152 8 44.9 37.4 27.8 1248 3
SM/SZ100 18.5 14.6 23.5 152 8 44.9 37.4 27.8 1248 3
SM/SZ110-120 18.5 14.6 23.5 172 8 44.9 37.4 29.8 1407 3
SM112 15.0 12.6 22.8 143 8 45.3 37.4 29.3 1197 3
SM124 15.0 12.6 22.8 143 8 45.3 37.4 29.3 1197 2
SM/SZ147 15.0 12.6 22.8 150 8 45.3 37.4 29.3 1248 2
SM/SZ148-161 18.5 14.6 26.4 194 6 44.9 37.4 31.1 1204 3
SM/SZ175-185 - SY185 18.5 15.7 27.5 234 6 44.9 37.4 34.5 1429 2
SY/SZ240 20.1 18.3 30.7 344 4 44.9 37.4 35.6 1400 2
SY/SZ300 20.1 18.3 30.7 355 4 44.9 37.4 36.0 1400 2
SY/SZ380 20.1 18.3 31.7 362 4 44.9 37.4 37.0 1426 2
* Nbr = number of compressors per pallet
Compressor
model
Connections
Motor
protection
Code no.
3 4 7 9
200-230/3/60
460/3/60
380-400/3/50
575/3/60
500/3/50
380/3/60
SM112 Brazed Internal 120H0610 120H0612 - 120H0614
SM124 Brazed Internal 120H0184 120H0186 - 120H0188
SM147 Brazed Internal 120H0190 120H0311 - 120H0198
SZ147 Brazed Internal - 120H1097 - -
Compressor
model
Connections
Motor
protection
Code no.
3 4 7 9
200-230/3/60
460/3/60
380-400/3/50
575/3/60
500/3/50
380/3/60
SM112 Brazed Internal 120H0609 120H0611 - 120H0613
SM124 Brazed Internal 120H0183 120H0185 - 120H0187
SM147 Brazed Internal 120H0189 120H0191 - 120H0197
SZ147 Brazed Internal - 120H1096 - -
Application guidelines
48
FRCC.PC.003.A5.22
