Ordering information & packaging
SM /SY compressors in single pack R22
Compressor
model
Connections
Motor
protection
Code no.
3 4 7 9
200-230/3/60
460/3/60
380-400/3/50
575/3/60
500/3/50
380/3/60
SM084 Brazed Internal SM084-3VI SM084-4VI SM084-7VI SM084-9VI
SM090 Brazed Internal SM090-3VI SM090-4VI SM090-7VI SM090-9VI
SM100 Brazed Internal SM100-3VI SM100-4VI SM100-7VI SM100-9VI
SM110 Brazed Internal SM110 -3VI SM110 - 4VI SM110 -7VI SM110-9VI
SM120 Brazed Internal SM120-3VI SM120-4VI SM120-7VI SM120-9VI
SM148 Brazed Internal SM148-3VAI SM148-4VAI SM148-7VAI SM148-9VAI
SM161 Brazed Internal SM161-3VAI SM161-4VAI SM161-7VAI SM161-9VAI
SM175
Brazed Thermostat SM175-3CAI SM175- 4CAI SM175-7CAI SM175-9CAI
Brazed Module 24V AC SM175-3PCI SM175-4PCI SM175-7PCI -
Rotolock Thermostat SM175-3RI SM175- 4RI SM175-7RI SM175-9RI
Rotolock Module 24V AC SM175-3SCI SM175- 4SCI SM175-7SCI -
SM185
Brazed Thermostat SM185-3CAI SM185-4CAI SM185-7CAI SM185-9CAI
Brazed Module 24 V AC SM185-3PCI SM185-4PCI SM185-7PCI -
Brazed Module 230 V AC - SM185-4XCI - SM185-9XCI
Rotolock Thermostat SM185-3RI SM185-4RI SM185-7RI SM185-9RI
Rotolock Module 24 V AC SM185-3SCI SM185-4SCI SM185-7SCI -
Rotolock Module 230 V AC - SM185-4YCI - SM185-9YCI
SY185 **
Brazed Thermostat - SY185-4CAI - -
Rotolock Thermostat - SY185-4RI - -
SY240
Brazed Module 24V AC - SY240A4CAI - -
Brazed Module 115-230V AC SY240A3CBI SY240A4CBI SY240A7CBI SY240A9CBI
Rotolock Module 24V AC - SY240A4PAI - -
Rotolock Module 115-230V AC SY240A3PBI SY240A4PBI SY240A7PBI SY240A9PBI
SY300
Brazed Module 24V AC - SY300A4CAI - -
Brazed Module 115-230V AC SY300A3CBI SY300A4CBI SY300A7CBI SY300A9CBI
Rotolock Module 24V AC - SY300A4PAI - -
Rotolock Module 115-230V AC SY300A3PBI SY300A4PBI SY300A7PBI SY300A9PBI
SY380
Brazed Module 24V AC - SY380A4CAI - -
Brazed Module 115-230V AC - SY380A4CBI - -
** No module version available
SM/SY compressors in industrial pack: use numbers from above table and replace the last digit by "M". Example: SY240A3CAM, except for voltage codes
6 and 7 available in single pack only
49
FRCC.PC.003.A5.22
Application guidelines
