Danfoss R22 User Manual

Technical specications
50 Hz data
Subject to modication without prior notication
For full data details and capacity tables refer to Online Datasheet Generator : www.danfoss.com/odsg
Rating conditions
Model
Nominal
Cap. 60 Hz
Nominal cooling capacity Power input COP E.E.R.
Swept
volume
Displace-
ment 
Oil
charge
Net
weight 
TR W Btu/h kW W/W Btu/h /W cu.in/rev cu.ft/h oz lbs
R22 SINGLE
SM084 7 20 400 69 600 6.12 3.33 11.4 6.99 703 112.08 141
SM090 7.5 21 800 74 400 6.54 3.33 11.4 7.35 741 112.08 143
SM100 8 23 100 78 800 6.96 3.33 11.4 7.76 782 112.0 8 143
SM110 9 25 900 88 400 7.82 3.32 11. 3 8.80 886 112 .08 161
SM112 9.5 27 600 94 200 7.92 3.49 11.9 9.25 931 112.0 8 141
SM120 10 30 100 102 700 8.96 3.36 11.5 10.17 1024 112.08 161
SM124 10 31 200 106 500 8.75 3.56 12.2 10.34 1042 112.08 141
SM147 12 36 000 122 900 10.08 3.57 12.2 11. 81 1190 112.0 8 148
SM148 12 36 100 123 200 10.8 3.34 11.4 12.14 1222 122.26 194
SM161 13 39 000 133 100 11.59 3.37 11. 5 13.22 1331 122.26 194
SM175 14 42 000 143 300 12.47 3.37 11. 5 14.22 1432 210.57 220
SM/SY185 15 45 500 155 300 13.62 3.34 11.4 15.25 1535 210.57 220
SY240 20 61 200 208 900 18.2 3.36 11. 5 21.22 2137 271.70 331
SY300 25 78 200 266 900 22.83 3.43 11.7 26.70 2687 271.70 346
SY380 30 94 500 322 500 27.33 3.46 11. 8 32.42 3263 285.28 348
R407C SINGLE
SZ084 7 19 300 65 900 6.13 3.15 10.8 6.99 703 112.0 8 141
SZ090 7.5 20 400 69 600 6.45 3.16 10.8 7. 35 741 112.08 143
SZ100 8 21 600 73 700 6.84 3.15 10.8 7.76 782 112.08 143
SZ110 9 24 600 84 000 7.76 3.17 10.8 8.80 886 112 .08 161
SZ120 10 28 600 97 600 8.99 3.17 10.8 10.17 1024 112.08 161
SZ147 12 34 900 119 10 0 9.92 3.52 12.0 11.81 1190 112.08 148
SZ148 12 35 100 119 800 10.99 3.19 10.9 12.14 1222 122.26 194
SZ161 13 37 900 129 700 11. 8 4 3.21 11.0 13.22 1331 122.26 194
SZ175 14 40 100 136 900 12.67 3.17 10.8 14.22 1432 210.57 220
SZ185 15 43 100 147 100 13.62 3.16 10.8 15.25 1535 210.57 220
SZ240 20 59 100 201 700 18.55 3.19 10.9 21.22 2137 271.70 331
SZ300 25 72 800 248 100 22.73 3.2 10.9 26.70 2687 271.70 346
SZ380 30 89 600 305 800 27.59 3.25 11.1 32.42 3263 285.28 348
TR = Ton of Refrigeration COP = Coecient Of Performance EER = Energy Eciency Ratio
 Displacement at nominal speed: 2900 rpm at 50 Hz, 3500 rpm at 60Hz  Net weight with oil charge
Data given for code 4 compressor, for full data details and capacity tables refer to Online Datasheet Generator: www.danfoss.com/ODSG
SM/SY compressors SZ compressors
Refrigerant R22 R407C
Frequency 50 Hz 50 Hz
Standard rating conditions ARI standard conditions -
Evaporating temperature 45°F 45°F (dew point)
Condensing temperature 130°F 130°F (dew point)
Sub-cooling 15°F 15°F
Superheat 20°F 20°F
