Technical specications
60 Hz data
Subject to modication without prior notication
For full data details and capacity tables refer to Online Datasheet Generator : www.danfoss.com/odsg
Rating conditions
SM/SY compressors SZ compressors
Refrigerant R22 R407C
Frequency 60 Hz 60 Hz
Standard rating conditions ARI standard conditions -
Evaporating temperature 45°F 45°F (dew point)
Condensing temperature 130°F 130°F (dew point)
Sub-cooling 15°F 15°F
Superheat 20°F 20°F
Model
Nominal
Cap. 60 Hz
Nominal cooling capacity Power input COP E.E.R.
Swept
volume
Displace-
ment 
Oil
charge
Net
weight 
TR W Btu/h kW W/W Btu/h /W cu.in/rev cu.ft/h oz lbs
R22 SINGLE
SM084 7 24600 84 000 7. 4 3.34 11.4 6.99 849 110 141
SM090 7.5 26400 90 100 7. 8 3.37 11.5 7. 35 894 110 143
SM100 8 27500 93 900 8.1 3.38 11.5 7.76 943 110 143
SM110 9 31600 107 800 9.3 3.38 11.5 8.80 1069 110 161
SM112 9.5 34000 116 000 9.6 3.53 12.1 9.25 1124 112 141
SM120 10 36 700 125 300 10.8 3.4 11.6 10.17 1236 110 161
SM124 10.5 37 700 128 700 10.6 3.56 12.2 10.34 1257 112 142
SM147 12 43 600 148 800 12.2 3.58 12.2 11.81 1435 112 148
SM148 12 43 800 149 500 13 3.37 11. 5 12.14 1476 122 194
SM161 13 47 600 162500 14.1 3.39 11.6 13.22 1606 122 194
SM175 14 51 100 174 400 15.3 3.34 11.4 14.22 1728 210 220
SM/SY185 15 55 300 188 700 16.3 3.39 11.6 15.25 1853 210 220
SY240 20 74 100 252 900 22.1 3.35 11.4 21.22 2579 272 331
SY300 25 94 500 322 500 27.5 3.43 11.7 26.70 3245 272 346
SY380 30 115 30 0 393 500 33.4 3.46 11.8 32.42 3939 285 348
R407C SINGLE
SZ084 7 22 500 76 800 7.1 3.19 10.9 6.99 849 110 141
SZ090 7.5 24 400 83 300 7.6 3.2 10.9 7. 35 894 110 143
SZ100 8 26 500 90 400 8.2 3.24 11.1 7.76 943 110 143
SZ110 9 30 100 102 700 9.3 3.24 11.1 8.80 1069 110 161
SZ120 10 34 800 118 800 10.7 3.24 11.1 10.17 1236 110 161
SZ147 12 42 300 144 300 12.03 3.52 12.0 11.81 1435 112 148
SZ148 12 42 600 145 400 13.3 3.19 10.9 12.14 1476 122 194
SZ161 13 46 000 157 000 14.3 3.21 11.0 13.22 1606 122 194
SZ175 14 48 700 166 200 15.3 3.19 10.9 14.22 1728 210 220
SZ185 15 51 800 176 800 16.4 3.15 10.8 15.25 1853 210 220
SZ240 20 71 100 242 700 22.7 3.14 10.7 21.22 2579 272 331
SZ300 25 87 900 300 000 27.5 3.2 10.9 26.70 3245 272 346
SZ380 30 107 300 366 200 33.5 3.2 10.9 32.42 3939 285 348
TR = Ton of Refrigeration COP = Coecient Of Performance EER = Energy Eciency Ratio
 Displacement at nominal speed: 2900 rpm at 50 Hz, 3500 rpm at 60Hz  Net weight with oil charge
Data given for code 4 compressor, for full data details and capacity tables refer to Online Datasheet Generator: www.danfoss.com/ODSG
Application guidelines
8
FRCC.PC.003.A5.22
