The temperature inside the terminal box may not
exceed 158°F. Consequently, if the compressor
is installed in an enclosure, precautions must be
taken to avoid that the temperature around the
compressor and in the terminal box would rise
too much. The installation of ventilation on the
enclosure panels may be necessary. If not, the
electronic protection module may not operate
properly. Any compressor damage related to this
will not be covered by Danfoss warranty. In the
same manner, cables must be selected in a way
to insure that terminal box temperature does not
exceed 158°F.
Terminal box temperature
Electrical data, connections and wiring
Three phase electrical characteristics
Locked Rotor Amp value is the higher current as
measured on mechanically blocked compressor
tested under nominal voltage. The LRA value
can be used as rough estimation for the starting
current. However in most cases, the real starting
current will be lower. A soft starter can be
applied to reduce starting current.
LRA (Locked Rotor Amp)
Compressor model
LRA MCC MMT Max. op. current Winding resistance
A A A A Ω
Motor voltage code 3
200-230V/3 ph/60 Hz
SM/SZ084 170 35 35 0.44
SM/SZ090 195 35 34 0.38
SM/SZ100 195 38 32 0.38
SM/SZ110 237 45 40 0.26
SM112 267 51 41 0.27
SM/SZ120 237 50 48 0.26
SM/SZ124 267 51 45 0.27
SM/SZ147 304 57 52 0.24
SM/SZ148 255 64 57 0.29
SM/SZ161 255 64 61 0.29
SM/SZ175 * 380 75 70 0.19
SM/SZ185 * 380 75 73 0.19
SY/SZ240 460 109 100 0.14
SY/SZ300 560 130 130 0.12
Motor voltage code 4
380-400V/3 ph/50 Hz
460V/3 ph/60 Hz
SM/SZ084 86 17 17 1.74
SM/SZ090 98 18.5 17 1.48
SM/SZ100 98 19 18 1.48
SM/SZ110 130 22 20 1.05
SM/SZ112 142 25 21 1.05
SM/SZ120 130 29 24 1.05
SM/SZ124 142 25 23 1.05
SM/SZ147 147 29 26 0.92
SM/SZ148 145 32 29 0.94
SM/SZ161 145 32 31 0.94
SM/SZ175 * 175 35 34 0.77
SM/SZ185 * 175 35 35 0.77
SY/SZ185 175 35 34 0.77
SY/SZ240 215 50 47 0.62
SY/SZ300 270 69 58 0.52
SY/SZ380 300 79 69 0.46
Motor voltage code 7
500V/3 ph/50 Hz
575V/3 ph/60 Hz
SM/SZ084 70 13 13 2.58
SM/SZ090 80 14 13 2.25
SM/SZ100 80 15 13 2.25
SM/SZ110 85 18 16 1.57
SM/SZ120 85 19 18 1.57
SM/SZ148 102 27 23 1.61
SM/SZ161 102 25 24 1.61
SM/SZ175 * 140 28 27 1.11
SM/SZ185 * 140 28 28 1.11
SY/SZ240 180 40 39 0.94
SY/SZ300 210 49 49 0.80
Motor voltage code 9
380V/3 ph/60 Hz
SM/SZ084 100 20 20 1.22
SM/SZ090 113 22 20 1.05
SM/SZ100 113 22 19 1.05
SM/SZ110 160 27 23 0.72
SM/SZ112 177 32 24 0.72
SM/SZ120 160 30 28 0.72
SM/SZ124 177 32 27 0.72
SM/SZ147 181 35 31 0.62
SM/SZ148 155 38 36 0.75
SM/SZ161 155 38 38 0.75
SM/SZ175 * 235 43 42 0.48
SM/SZ185 * 235 43 43 0.48
SY/SZ240 260 62 62 0.42
SY/SZ300 305 74 74 0.36
* For versions with electronic module, see datasheet for electrical data
