VFD500 high performance vector control frequency inverter user manual Chapter 5 function code table
P42.06
PLC step 2
running time
0.0～6553.5 unit depend on P42.21
0.0
☆
P42.07
PLC step 3
running time
0.0～6553.5 unit depend on P42.21
0.0
☆
P42.08
PLC step 4
running time
0.0～6553.5 unit depend on P42.21
0.0
☆
P42.09
PLC step 5
running time
0.0～6553.5 unit depend on P42.21
0.0
☆
P42.10
PLC step 6
running time
0.0～6553.5 unit depend on P42.21
0.0
☆
P42.11
PLC step 7
running time
0.0～6553.5 unit depend on P42.21
0.0
☆
P42.12
PLC step 8
running time
0.0～6553.5 unit depend on P42.21
0.0
☆
P42.13
PLC step 9
running time
0.0～6553.5 unit depend on P42.21
0.0
☆
P42.14
PLC step 10
running time
0.0～6553.5 unit depend on P42.21
0.0
☆
P42.15
PLC step 11
running time
0.0～6553.5 unit depend on P42.21
0.0
☆
P42.16
PLC step 12
running time
0.0～6553.5 unit depend on P42.21
0.0
☆
P42.17
PLC step 13
running time
0.0～6553.5 unit depend on P42.21
0.0
☆
P42.18
PLC step 14
running time
0.0～6553.5 unit depend on P42.21
0.0
☆
P42.19
PLC step 15
running time
0.0～6553.5 unit depend on P42.21
0.0
☆
P42.20
PLC step 16
running time
0.0～6553.5 unit depend on P42.21
0.0
☆
P42.21
PLC running
time unit
0:S;1:minute;2:hour
0
☆
P42.22
PLC step 1-4
ACCEL/DECEL
time selector
Unit’digit:step 1 ACCEL/DECEL time
selector#
ten’digit: step 2 ACCEL/DECEL time
selector#
Hundred’s: step 3 ACCEL/DECEL time
selector#
Thousand’unit:step 4 ACCEL/DECEL time
selector#
0- ACCEL/DECEL time 1#
1- ACCEL/DECEL time 2#
2- ACCEL/DECEL time 3#
3- ACCEL/DECEL time 4
0000
☆
P42.23
PLC step 5-8
ACCEL/DECEL
time selector
Unit’digit: ACCEL/DECEL time 5#
Ten’digit: ACCEL/DECEL time 6#
Hundred’digit: ACCEL/DECEL time 7#
Thousand’digit: ACCEL/DECEL time 8#
0- ACCEL/DECEL time 1#
1- ACCEL/DECEL time 2#
2- ACCEL/DECEL time 3#
3- ACCEL/DECEL time 4
0000
☆
103
