VFD500 high performance vector control frequency inverter user manual Chapter 5 function code table
Torque control input
source
0：Digital setting(P14.01)
1：AI1
2：AI2
3：AI3(IO expansion board)
4：AI4(IO expansion board)
5：HDI
6：Communication
-200.0～200.0%
The torque reference greater than 0 indicates
that the direction of the torque is the same as the
forward direction of the motor; less than 0
indicates that the direction of the torque is the
same as the reverse direction of the motor.
Benchmark 10.0%～300.0%
Notice:It is torque benchmarks as torque
reference for analog inputs and high frequency
pulse input also it is the ultimate output torque
during torque control.
0.000s～60.000s
Notice:Torque reference time from zero to motor
rated torque
Torque control
Deceleration time
0.000s～60.000s
Notice:Torque given time from motor rated torque
to zero
0：digital setting(P14.06)
1：AI1
2：AI2
3：AI3(IO expansion board)
4：AI4（IO expansion board）
5：HDI high frequency pulse input
6：Communication
When this parameter is not 0: If the given speed
limit value is positive, the speed limit value in the
reverse direction is P14.07; if the given speed
limit value is negative, the speed limit value in
the positive direction is P14.06 .
Speed limit value setting
Relative to maximum frequency：0.0%～100.0%
Notice:Speed limit for reverse speed direction
not specified by the speed limit source
Torque setting over limit
speed
0: Symmetrical torque command
After the motor speed exceeds the speed limit
value, the torque input source sets the absolute
value of the torque reference, and the direction of
the torque is always the braking force.
1: Enter speed mode
After the motor speed exceeds the speed limit
value, enter the speed mode, and the inverter will
limit the speed to within the speed limit value as
much as possible.
