Chapter 7 Selection guide of inverter Accessory VFD500 high performance vector control frequency inverter user
manual
7.4 CANopen exentsion card
The VFD500-CAN1 communication card is a CANopen slave communication
card for connecting VFD500 series inverters to the CANopen network. Please
note that CANopen communication cannot be used simultaneously with
Modbus communication.
Product Features:
Support Node Guard protocol, the master station can use this function to
query device status;
Support the Heartbeat protocol, and the slave station periodically reports the
current status to the primary station;
Support NMT network management protocol;
SDO only supports the accelerated transfer mechanism, which can transfer up
to 4 bytes and can be used to read and write the inverter parameters.
Support 4 groups of PDO
7
PT
DIP switch switching mode:
DIP switch SW1 SW2 SW3
AI4 ON ON ON
PT100 OFF OFF OFF
PT1000 OFF OFF ON
KTY84-130 OFF ON ON
8
DI9
Digital input 9
Input frequency:
0~200Hz
Voltage range:
0~30V
9
DI7
Digital input 7
11
AI3
Analog input 3 input 0~10V
12
DO6
Open collector output 6
Voltage range:
0~24V
13
DO4
Open collector output 4
14
DO5
Open collector output 5
15
DO3
Open collector output 3
17
DI8
Digital input 8
Input frequency:
0~200Hz
Voltage range:
0~30V
18
DI6
Digital input 6
123
