VFD500 high performance vector control frequency inverter user manual Chapter 5 function code table
25 Group Fault tracking parameter
- see detail chapter 6 fault diagnosis and
solution
Output
frequency at
fault
Running mode
status 1at fault
- see Parameter r27.10 in detail
Input terminal
status at fault
Bit0~Bit6 corresponds to DI1~DI7
Bit12~Bit15 corresponds to VDI1~VDI4
Accumulated
working time at
fault
Frequency
source at fault
Unit:0.1% compared to motor rated torque
Electrical angle
at fault
Running mode
status 2 1at fault
See Parameter r27.11 in detail
Input terminal
status at fault
Define as per unit,0:ineffective,1:effective
Bit0: DO1; Bit1: DO2
Bit2: relay; Bit3~Bit7: reserved;
Bit8: VDO1; Bit9: VDO2
Heat sink
temperature at
fault
For the fault type, see theChapter6Fault
Diagnosis and Solution
For the fault type, see theChapter6Fault
Diagnosis and Solution
26 Group Fault recording parameter
Output
frequency at
fault
Running mode
status 1at fault
