Chapter3 product appearance and wiring VFD500 high performance vector control frequency inverter user manual
!
Figure 3-9 SIZE K~O(315KW-710KW) Dimensions
Table 3-1 VFD500 series appearance and installation dimension
SIZE
Appearance and installation dimension（mm）
A
B
B2
H
H1
H2
W
D
Φd
Mountin
g
screws
0.75KW-4KW
87
206.5
/
215
/
/
100
170
ø5.0
M4X16
5.5KW-7.5KW
113
239.5
/
250
/
/
130
180
ø5.0
M4X16
11KW-15KW
153
299
/
310
/
/
170
193
Ø6.0
M5X16
18.5KW-22K
W
165
350
/
370
335
/
210
205
Ø6.0
M5X16
30KW-37KW
218
438
/
452.
5
424
/
260
230
Ø7.0
M6X16
45KW-55KW
250
535
/
555
520
/
320
275
Ø10.
0
M8X20
75KW-90KW
280
620
/
640
605
/
350
290
Ø10.
0
M8X20
110KW
280
695
915
715
660
935
370
313
Ø11.
0
M8X25
132KW-160K
W
280
705
925
725
670
945
360
338
Ø11.
0
M8X25
19
