VFD500 high performance vector control frequency inverter user manual Chapter 5 function code table
P43.05
Delay unit 1
descending
edge delay time
0.0s～3000.0s
0.0s
☆
P43.06
Delay unit 2
input parameter
selection
00.00-98.99(function code index)
00.00
☆
P43.07
Delay unit 2
input bit
selection
0-15
0
☆
P43.08
Delay unit2
rising edge
delay time
0.0s～3000.0s
0.0s
☆
P43.09
Delay
unit2descending
edge delay time
0.0s～3000.0s
0.0s
☆
P43.10
Delay unit 3
input parameter
selection
00.00-98.99(function code index)
00.00
☆
P43.11
Delay unit 3
input bit
selection
0-15
0
☆
P43.12
Delay unit3
rising edge
delay time
0.0s～3000.0s
0.0s
☆
P43.13
Delay
unit3descending
edge delay time
0.0s～3000.0s
0.0s
☆
P43.14
Delay unit 4
input parameter
selection
00.00-98.99(function code index)
00.00
☆
P43.15
Delay unit 4
input bit
selection
0-15
0
☆
P43.16
Delay unit4
rising edge
delay time
0.0s～3000.0s
0.0s
☆
P43.17
Delay
unit4descending
edge delay time
0.0s～3000.0s
0.0s
☆
44 Group Variable selector and logic block
r44.00
Variable selector
1～4 output
bit0～3 indicate the output of variable
selector 1-4
-
●
r44.01
Logic block 1～4
output
bit0～3 indicate the output of logic block 1～
4
-
●
P44.02
Variable selector
1 input
parameter
00.00～98.99(Function code index)
00.00
☆
P44.03
Variableselector
1 threshold
00.00～98.99(Function code index)
00.00
☆
P44.04
Variable selector
1 logic mode
0:>; 1:<; 2:≥;3:≤;4:=; 5:≠; 6:≈
0
☆
P44.05
Variableselector
1 hysteresis
width
0～65535
0
☆
105
