VFD500 high performance vector control frequency inverter user manual Chapter 5 function code table
05 Group Analog and Pulse output
r05.00
Actual output Pulse
frequency
0.00kHz～50.00kHz
-
●
P05.01
HDO Pulse Output type
0：Common numeric output (DO2 P07.02)
1：high frequency pulse output (Hdo)
0
☆
P05.02
HDO output source
selection
0：Running frequency（0～max frequency）
1：Set frequency（0～max frequency）
2：output current（0～2times motor rated
current）
3：output torque(0～3times motor rated torque)
4：set torque(0～3times motor rated torque)
5：output voltage（0～2times motor rated
voltage）
6: DC bus voltage（0～2times drives standard
DC bus voltage）
7: output power（0～2times motor rated
power）
8:encoder rotating speed(0-maximum frequency
rotating speed)
9: AI1（0.00～10.00V）
10: AI2（0.00～10.00V）
11: AI3（0.00～10.00V）
12: AI4（0.00～10.00V）
0
☆
P05.03
HDO Minimum output
pulse frequency
0.00kHz～50.00kHz
HDO terminal output pulse frequencywhen
Output signal source=0
1.00kHz
☆
P05.04
HDO Max output pulse
frequency
0.00kHz～50.00kHz
HDO terminal output pulse frequencywhen
Output signal source=maximum value
30.00kHz
☆
r05.05
AO1 actual value
0.0%～100.0%
-
●
P05.06
AO1 output function signal
selection
Same as P05.02 function description
0
☆
P05.07
AO1 output offset
-100.0%～100.0%
0.0%
☆
P05.08
AO1 output gain
-10.00～10.00
1.00
☆
The output error of AO1 can be corrected by P05.07 and P05.08, or the mapping relationship between signal
source and actual output can be changed. The formula is:
AO.c = P05.07 + P05.08 × AO.pAO.c: the actual output of AO1;
AO.p: AO1 Value before correction and AO.c, AO.p, 100.0% of P05.07 corresponds to 10V or 20mA.
r05.09
AO2 actual value
0.0%～100.0%
-
●
P05.10
AO2 output function signal
selection
Same as P05.02 function description
0
☆
P05.11
AO2 output offset
-100.0%～100.0%
0.0%
☆
P05.12
AO2 gain
-10.00～10.00
1.00
☆
The output error of AO2 can be corrected by P05.11 and P05.12, or the mapping relationship between signal
source and actual output can be changed. The formula is:
AO.c = P05.11 + P05.12 × AO.pAO.c: the actual output of AO2;
AO.p: AO2 value before correction and AO.c, AO.p, 100.0% of P05.11 corresponds to 10V or 20mA.
59
