Chapter 5 Function code VFD500 high performance vector control frequency inverter user manual
P01.40
UP/DOWN Control
Unit’digit：
0：Zero clearing in non-running
1：Zero clearning when UP/DOWN command
not effective
2：Not zero cleaning (decide by remembering
digit when power failure
Ten’s digit：
0：Non-zero cleaning at power failure
1:Save at power failure UP/DOWN offset
Hundred’s digit: UP/DOWN near to zero
0: Forbidden
1:Enable
Thousand’s digit up and down action mode
0:Superposition
1:Gain effect
0002
★
P01.41
Droop control gains
0.00～1.00
Rotation speed drop value based on Rated
load（relative to maximum frequency）
Frequency drop volume:Max
frequency*P01.41*Current load/rated load
0.00
☆
P01.42
Droop control filtering
time
0.000s～10.000s
0.050s
☆
When several motors drive the same load, each motor's load is different because of the difference of
motor's rated speed. The load of different motors can be balanced through droop control function which
makes the speed droop along with load increase.
When the motor outputs rated torque, actual frequency drop is equal to P1.41. User can adjust this
parameter from small to big gradually during commissioning.
P01.43
Textile frequency setting
0: relative to center of textile frequency#
1: relative to maximum frequency
0
☆
P01.44
Textile frequency
0.0%～100% relative to center of textile
frequency P01.43 = 0Textile frequency Aw =
P01.44 * center frequency
P01.43 = 1: Textile frequency Aw = P01.44 *
max frequency
0.0%
☆
P01.45
Jump frequency
0.0%～50.0% relative to textile frequency
0.0%
☆
P01.46
Textile period
0.1s～3000.0s
10.0s
☆
P01.47
Triangle wave rising time
coeffcient
0.1%～100.0% relative to textile period
50.0%
☆
Function
code
Parameter name
Description
Default
Property
48
