Page #59 background imageLoading...
Page #59 background image
Chapter 5 Function code VFD500 high performance vector control frequency inverter user manual
P04.11
AI 2 Curve setting
Unit’sAI curve selection
0curve A
1curve B
2Curve C
3Curve D
Ten un itwhen input signal lower than minimum input #
0equal to minimum input
1equal to 0.0%
01
P04.12
AI2 filter time
0.000s10.000s
0.100s
r04.13
AI 2 actual value
0.00V10.00V ( it is used to view the port voltage of AI2.
When AI2 is a current type (0~20mA) input, multiplying this
value by 2 is the input current (mA) of the AI2 port.)
-
r04.14
AI 2 Conversion
value
-100.0%100.0%(It is used to view the output of the AI2
mapped curve)
-
P04.15
AI 3(option card)
Curve setting
Unit’sAI curve selection
0curve A
1curve B
2Curve C
3Curve D
Ten un itwhen input signal lower than minimum input #
0equal to minimum input
1equal to 0.0%
02
P04.16
AI3 (option card)
filter time
0.000s10.000s
0.100s
r04.17
AI3(option card)
actual value
0.00V10.00V ( it is used to view the port voltage of AI3.
When AI3 is a current type (0~20mA) input, multiplying this
value by 2 is the input current (mA) of the AI3 port.)
-
r04.18
AI3(option card)
Conversion value
-100.0%100.0%(It is used to view the output of the AI3
mapped curve)
-
P04.19
AI 4(option card)
Curve setting
Unit’sAI curve selection
0curve A
1curve B
2Curve C
3Curve D
Ten un itwhen input signal lower than minimum input #
0equal to minimum input
1equal to 0.0%
03
P04.20
AI4(option card)
filter time
0.000s10.000s
0.100s
r04.21
AI4(option card)
actual value
0.00V10.00V ( it is used to view the port voltage of AI4.
When AI4 is a current type (0~20mA) input, multiplying this
value by 2 is the input current (mA) of the AI4 port.)
-
r04.22
AI4(option card)
Conversion value
-100.0%100.0%(It is used to view the output of the AI4
mapped curve)
-
Functio
n code
Parameter
name
Description
Default
Propert
y
56
