Danfoss VLT AHF 005 Operating Instructions

F2 IP 21/54 - NEMA 1/12 F4 IP 21/54 - NEMA 1/12
225.0
(8.85)
2281
(89.8)
1499
(59.0)
Ø29
(1.1)
1804
(71.0)
2206
(86.9)
606
(23.8)
130BB028.10
1
1
130BB030.10
2280
(89.7)
2205
(86.8)
1497 (58.9)
2401
(94.5)
Ø29
(1.1)
225.0
(8.85)
604
(23.8)
1) Minimum clearance from ceiling
Table 3.2
Mechanical Installation VLT HVAC Drive FC 102 Operating Instructions
MG11F402 - Rev. 2013-12-16 17
3 3
