Danfoss VLT AQUA Drive FC 202 Instruction Manual

Line Power Supply 3 x 380–480 V AC - Normal overload 110% for 1 minute
Adjustable frequency drive
Typical Shaft Output [kW]
P11K
11
P15K
15
P18K
18.5
P22K
22
P30K
30
P37K
37
P45K
45
P55K
55
P75K
75
P90K
90
Typical Shaft Output [HP] at 460 V 15 20 25 30 40 50 60 75 100 125
IP20/NEMA Chassis
*
B3 B3 B3 B4 B4 B4 C3 C3 C4 C4
IP21/NEMA 1 B1 B1 B1 B2 B2 C1 C1 C1 C2 C2
IP55/NEMA 12 B1 B1 B1 B2 B2 C1 C1 C1 C2 C2
IP66 B1 B1 B1 B2 B2 C1 C1 C1 C2 C2
Output current
Continuous (3 x 380–440 V) [A] 24 32 37.5 44 61 73 90 106 147 177
Intermittent (3 x 380-440 V) [A] 26.4 35.2 41.3 48.4 67.1 80.3 99 117 162 195
Continuous (3 x 441–480 V) [A] 21 27 34 40 52 65 80 105 130 160
Intermittent (3 x 441–480 V) [A] 23.1 29.7 37.4 44 61.6 71.5 88 116 143 176
Continuous kVA (400 V AC) [kVA] 16.6 22.2 26 30.5 42.3 50.6 62.4 73.4 102 123
Continuous kVA (460 V AC) [kVA] 16.7 21.5 27.1 31.9 41.4 51.8 63.7 83.7 104 128
Max. input current
Continuous (3 x 380–440 V) [A] 22 29 34 40 55 66 82 96 133 161
Intermittent (3 x 380-440 V) [A] 24.2 31.9 37.4 44 60.5 72.6 90.2 106 146 177
Continuous (3 x 441–480 V) [A] 19 25 31 36 47 59 73 95 118 145
Intermittent (3 x 441–480 V) [A] 20.9 27.5 34.1 39.6 51.7 64.9 80.3 105 130 160
Max. pre-fuses
1)
[A]
63 63 63 63 80 100 125 160 250 250
Additional specifications
Estimated power loss at rated
max. load [W]
4)
278 392 465 525 698 739 843 1083 1384 1474
Max. cable size (line power, motor,
brake)
[mm
2
]/(AWG)
2)
[10]/(7) [35]/(2) [50]/(1/0)
[120]/
(4/0)
[120]/
(4/0)
Weight enclosure IP20 (lb [kg]) 26.46
[12]
26.46
[12]
26.46
[12]
51.81
[23.5]
51.81
[23.5]
51.81
[23.5]
77.16
[35]
77.16
[35]
110.23
[50]
110.23
[50]
Weight enclosure IP21 (lb [kg]) 50.71
[23]
50.71
[23]
50.71
[23]
59.53
[27]
59.53
[27]
99.21
[45]
99.21
[45]
99.21
[45]
143.3
[65]
143.3
[65]
Weight enclosure IP55 (lb [kg]) 50.71
[23]
50.71
[23]
50.71
[23]
59.53
[27]
59.53
[27]
99.21
[45]
99.21
[45]
99.21
[45]
143.3
[65]
143.3
[65]
Weight enclosure IP66 (lb [kg]) 50.71
[23]
50.71
[23]
50.71
[23]
59.53
[27]
59.53
[27]
99.21
[45]
99.21
[45]
99.21
[45]
143.3
[65]
143.3
[65]
Efficiency
3)
0.98 0.98 0.98 0.98 0.98 0.98 0.98 0.98 0.98 0.99
Table 10.6 Line Power Supply 3 x 380–480 V AC - Normal Overload 110% for 1 Minute
*
B3+B4 and C3+C4 may be converted to IP21 using a conversion kit
(contact Danfoss)
