Danfoss VLT AQUA Drive FC 202 Installation Manual

2
1
16
15
14
13
12
11
10
8
7
6
5
4
9
3
130BX330.11
1 Fan transformer 9 Fan door cover
2 DC link inductor 10 Module heatsink fan
3 Top cover plate 11 Inverter module
4 MDCIC board 12 Panel connectors
5 Control card 13 DC fuse
6 SMPS fuse and fan fuse 14 Mounting bracket
7 Motor output bus bar 15 (+) DC bus bar
8 Brake output bus bar 16 (-) DC bus bar
Figure 1.9 Frame Size F18 Inverter Cabinet
Introduction
VLT
®
AQUA Drive FC 202 Low Harmonic Drive
14 Danfoss A/S © 10/2015 All rights reserved. MG21B322
