Frame size Bussmann PN Rating
D, E, F FNQ-R-3 3 A, 600 V
Table 8.18 Transformer Fuse (Line Contactor)
Frame size Bussmann PN Rating
D, E, F FNQ-R-1 1 A, 600 V
Table 8.19 Soft Charge Fuses
8.5 General Torque Tightening Values
For fastening hardware described in this manual, use the torque values in Table 8.20. These values are not intended for
fastening IGBTs. See the instructions included with those replacement parts for correct values.
Shaft Size Driver Size Torx/Hex [mm] Torque [Nm] Torque [in-lbs]
M4 T-20/7 1.0 10
M5 T-25/8 2.3 20
M6 T-30/10 4.0 35
M8 T-40/13 9.6 85
M10 T-50/17 19.2 170
M12 18/19 19 170
Table 8.20 Torque Values
