Danfoss VLT AQUA Drive FC 202

8.2 Mechanical Dimensions
576,8
[22.7]
1915,91
[75.4]
1781,7
[70.1]
1698,3
[66.9]
1755,5
[69.1]
411,0
[16.2]
115,5
[4.5]
139,0
[5.5]
443,0
[17.4]
611,0
[24.1]
663,5
[26.1]
843,5
[33.2]
1568,3
[61.7]
807,3
[31.8]
677,3
[26.7]
929.2
[36.6]
377,8
[14.9]
130BE140.10
251,0
[9.9]
221,0
[8.7]
301,9
[11.9]
369,0
[14.5]
664,4
[26.2]
864,4
[34.0]
Figure 8.5 Enclosure Size D1n
Specications
VLT
®
AQUA Drive FC 202 Low Harmonic Drive
