Illustration 4.30: Active Filter, frame size F17
Section shown
↓
1) Line 2) Bus bars to rectifier section of drive
R S T 3) Fuse block
L1 L2 L3
VLT AQUA Low Harmonic Drive Operating In-
structions 4 How to Install
MG.20.T1.02 - VLT
®
is a registered Danfoss trademark 47
