4.3.7 Terminal Locations - Frame size F
Terminal locations - Filter
Illustration 4.17: Terminal locations - Filter (Left side, front and right side view). The gland plate is 42 mm
below .0 level.
1) Earth ground bar
Section shown
4 How to Install
VLT AQUA Low Harmonic Drive Operating In-
structions
32 MG.20.T1.02 - VLT
®
is a registered Danfoss trademark
