Danfoss vlt aqua Operating Instructions

Par.
No. #
Parameter description Default value 4-set-up Change dur-
ing operation
Conver-
sion index
Type
25-8* Status
25-80 Cascade Status 0 N/A All set-ups TRUE 0
VisStr[2
5]
25-81 Pump Status 0 N/A All set-ups TRUE 0
VisStr[2
5]
25-82 Lead Pump 0 N/A All set-ups TRUE 0 Uint8
25-83 Relay Status 0 N/A All set-ups TRUE 0
VisStr[4
]
25-84 Pump ON Time 0 h All set-ups TRUE 74 Uint32
25-85 Relay ON Time 0 h All set-ups TRUE 74 Uint32
25-86 Reset Relay Counters [0] Do not reset All set-ups TRUE - Uint8
25-9* Service
25-90 Pump Interlock [0] Off All set-ups TRUE - Uint8
25-91 Manual Alternation 0 N/A All set-ups TRUE 0 Uint8
6.4.22 Analog I/O Option MCB 109 26-**
Par.
No. #
Parameter description Default value 4-set-up Change dur-
ing operation
Conver-
sion index
Type
26-0* Analog I/O Mode
26-00 Terminal X42/1 Mode [1] Voltage All set-ups TRUE - Uint8
26-01 Terminal X42/3 Mode [1] Voltage All set-ups TRUE - Uint8
26-02 Terminal X42/5 Mode [1] Voltage All set-ups TRUE - Uint8
26-1* Analog Input X42/1
26-10 Terminal X42/1 Low Voltage 0.07 V All set-ups TRUE -2 Int16
26-11 Terminal X42/1 High Voltage 10.00 V All set-ups TRUE -2 Int16
26-14 Term. X42/1 Low Ref./Feedb. Value 0.000 N/A All set-ups TRUE -3 Int32
26-15 Term. X42/1 High Ref./Feedb. Value 100.000 N/A All set-ups TRUE -3 Int32
26-16 Term. X42/1 Filter Time Constant 0.001 s All set-ups TRUE -3 Uint16
26-17 Term. X42/1 Live Zero [1] Enabled All set-ups TRUE - Uint8
26-2* Analog Input X42/3
26-20 Terminal X42/3 Low Voltage 0.07 V All set-ups TRUE -2 Int16
26-21 Terminal X42/3 High Voltage 10.00 V All set-ups TRUE -2 Int16
26-24 Term. X42/3 Low Ref./Feedb. Value 0.000 N/A All set-ups TRUE -3 Int32
26-25 Term. X42/3 High Ref./Feedb. Value 100.000 N/A All set-ups TRUE -3 Int32
26-26 Term. X42/3 Filter Time Constant 0.001 s All set-ups TRUE -3 Uint16
26-27 Term. X42/3 Live Zero [1] Enabled All set-ups TRUE - Uint8
26-3* Analog Input X42/5
26-30 Terminal X42/5 Low Voltage 0.07 V All set-ups TRUE -2 Int16
26-31 Terminal X42/5 High Voltage 10.00 V All set-ups TRUE -2 Int16
26-34 Term. X42/5 Low Ref./Feedb. Value 0.000 N/A All set-ups TRUE -3 Int32
26-35 Term. X42/5 High Ref./Feedb. Value 100.000 N/A All set-ups TRUE -3 Int32
26-36 Term. X42/5 Filter Time Constant 0.001 s All set-ups TRUE -3 Uint16
26-37 Term. X42/5 Live Zero [1] Enabled All set-ups TRUE - Uint8
26-4* Analog Out X42/7
26-40 Terminal X42/7 Output [0] No operation All set-ups TRUE - Uint8
26-41 Terminal X42/7 Min. Scale 0.00 % All set-ups TRUE -2 Int16
26-42 Terminal X42/7 Max. Scale 100.00 % All set-ups TRUE -2 Int16
26-43 Terminal X42/7 Bus Control 0.00 % All set-ups TRUE -2 N2
26-44 Terminal X42/7 Timeout Preset 0.00 % 1 set-up TRUE -2 Uint16
26-5* Analog Out X42/9
26-50 Terminal X42/9 Output [0] No operation All set-ups TRUE - Uint8
26-51 Terminal X42/9 Min. Scale 0.00 % All set-ups TRUE -2 Int16
26-52 Terminal X42/9 Max. Scale 100.00 % All set-ups TRUE -2 Int16
26-53 Terminal X42/9 Bus Control 0.00 % All set-ups TRUE -2 N2
26-54 Terminal X42/9 Timeout Preset 0.00 % 1 set-up TRUE -2 Uint16
26-6* Analog Out X42/11
26-60 Terminal X42/11 Output [0] No operation All set-ups TRUE - Uint8
26-61 Terminal X42/11 Min. Scale 0.00 % All set-ups TRUE -2 Int16
26-62 Terminal X42/11 Max. Scale 100.00 % All set-ups TRUE -2 Int16
26-63 Terminal X42/11 Bus Control 0.00 % All set-ups TRUE -2 N2
26-64 Terminal X42/11 Timeout Preset 0.00 % 1 set-up TRUE -2 Uint16
6 How to Programme the Low Harmonic Drive
VLT AQUA Low Harmonic Drive Operating In-
structions
142 MG.20.T1.02 - VLT
®
is a registered Danfoss trademark
6
