[89] Date and Time Readout Displays the current date and time.
[953] Profibus Warning Word Displays Profibus communication warnings.
[1005] Readout Transmit Error Counter View the number of CAN control transmission errors since the last power-up.
[1006] Readout Receive Error Counter View the number of CAN control receipt errors since the last power-up.
[1007] Readout Bus Off Counter View the number of Bus Off events since the last power-up.
[1013] Warning Parameter View a DeviceNet-specific warning word. One separate bit is assigned to every warning.
[1115] LON Warning Word Shows the LON-specific warnings.
[1117] XIF Revision Shows the version of the external interface file of the Neuron C chip on the LON option.
[1118] LON Works Revision Shows the software version of the application program of the Neuron C chip on the LON option.
[1500] Operating Hours View the number of running hours of the adjustable frequency drive.
[1501] Running Hours View the number of running hours of the motor.
[1502] kWh Counter View the line power consumption in kWh.
[1600] Control Word View the control word sent from the adjustable frequency drive via the serial communication port
in hex code.
[1601] * Reference [Unit] Total reference (sum of digital/analog/preset/bus/freeze ref./catch up and slow-down) in selected
unit.
[1602] Reference % Total reference (sum of digital/analog/preset/bus/freeze ref./catch up and slow-down) in percent.
[1603] Status Word Present status word
[1605] Main Actual Value [%] One or more warnings in a Hex code
[1609] Custom Readout View the user-defined readouts as defined in par. 0-30, 0-31 and 0-32.
[1610] Power [kW] Actual power consumed by the motor in kW.
[1611] Power [hp] Actual power consumed by the motor in HP.
[1612] Motor Voltage Voltage supplied to the motor.
[1613] Motor Frequency Motor frequency, i.e., the output frequency of the adjustable frequency drive in Hz.
[1614] Motor Current Phase current of the motor measured as effective value.
[1615] Frequency [%] Motor frequency, i.e., the output frequency from the adjustable frequency drive in percent.
[1616] Torque [Nm] Present motor load as a percentage of the rated motor torque.
[1617] Speed [RPM] Speed in RPM (revolutions per minute), i.e., the motor shaft speed in closed-loop based on the
entered motor nameplate data, the output frequency and the load on the adjustable frequency drive.
[1618] Motor Thermal Thermal load on the motor, calculated by the ETR function. See also parameter group 1-9* Motor
Temperature.
[1622] Torque [%] Shows the actual torque produced, in percentage.
[1630] DC Link Voltage Intermediate circuit voltage in the adjustable frequency drive.
[1632] BrakeEnergy/s Present braking energy transferred to an external brake resistor.
Stated as an instantaneous value.
[1633] BrakeEnergy/2 min Braking energy transferred to an external brake resistor. The mean power is calculated continuously
for the most recent 120 seconds.
[1634] Heatsink Temp. Present heatsink temperature of the adjustable frequency drive. The cut-out limit is 203° ± 9°F [95°
± 5°C]; cutting back in occurs at 158° ± 9°F [70° ± 5°C].
[1635] Thermal Drive Load Percentage load of the inverters
[1636] Inv. Nom. Current Nominal current of the adjustable frequency drive
[1637] Inv. Max. Current Maximum current of the adjustable frequency drive
[1638] SL Control State State of the event executed by the control
[1639] Control Card Temp. Temperature of the control card.
[1650] External Reference Sum of the external reference as a percentage, i.e., the sum of analog/pulse/bus.
5 How to program the adjustable frequency
drive
VLT AQUA High Power Instruction Manual
5-10
MG.20.P3.22 - VLT
®
is a registered Danfoss trademark
5
