Danfoss vlt aqua User Manual

[102] Feedback +-200% : -200% to +200% of par. 20-14
[103] Motor cur. 0-Imax : 0 - Inverter Max. Current (par. 16-37)
[104] Torque 0-Tlim : 0 - Torque limit (par. 4-16)
[105] Torque 0-Tnom : 0 - Motor rated torque
[106] Power 0-Pnom : 0 - Motor rated power
[107] Speed 0-HighLim : 0 - Speed High Limit (par. 4-13 and par. 4-14)
[113] Ext. Closed-loop 1 0 - 100%
[114] Ext. Closed-loop 2 0 - 100%
[115] Ext. Closed-loop 3 0 - 100%
[130] Out fr 0-100 4-20 :0–100 Hz
[131] Reference 4-20mA Minimum Reference - Maximum Reference
[132] Feedback 4-20mA -200% to +200% of par. 20-14
[133] Motor cur. 4-20mA 0 - Inverter Max. Current (par. 16-37
Inv. Max. Current )
[134] Torq.0-lim 4-20mA :0 - Torque limit (par. 4-16)
[135] Torq.0-nom 4-20mA :0 - Motor rated torque
[136] Power 4-20mA 0 - Motor rated power
[137] Speed 4-20mA 0 - Speed High Limit (par. 4-13 and par. 4-14)
[139] Bus ctrl. 0 - 100%
[140] Bus ctrl. 4-20 mA 0 - 100%
[141] Bus ctrl t.o. 0 - 100%
[142] Bus ctrl 4-20mA t.o. 0 - 100%
[143] Ext. CL 1 4-20 mA 0 - 100%
[144] Ext. CL 2 4-20 mA 0 - 100%
[145] Ext. CL 3 4-20 mA 0 - 100%
NOTE!
Values for setting the minimum reference is found in open-loop par. 3-02
Minimum Reference and for closed-loop par. 20-13 Minimum Reference/
Feedb.
- values for maximum reference for open-loop is found in par. 3-03 Maximum Reference and for closed-loop par. 20-14 Maximum Reference/
Feedb.
.
6-51 Terminal 42 Output Min Scale
Range: Function:
0.00 %* [0.00 - 200.00 %]
VLT AQUA High Power Instruction Manual
5 How to program the adjustable frequency
drive
MG.20.P3.22 - VLT
®
is a registered Danfoss trademark 5-33
5
