5.3.15 16-** Data Readouts
Par.
No. #
Parameter description Default value 4-set-up Change dur-
ing operation
Conver-
sion index
Type
16-0* General Status
16-00 Control Word 0 N/A All set-ups TRUE 0 V2
16-01 Reference [Unit] 0.000 ReferenceFeedbackUnit All set-ups TRUE -3 Int32
16-02 Reference % 0.0 % All set-ups TRUE -1 Int16
16-03 Status Word 0 N/A All set-ups TRUE 0 V2
16-05 Main Actual Value [%] 0.00 % All set-ups TRUE -2 N2
16-09 Custom Readout 0.00 CustomReadoutUnit All set-ups TRUE -2 Int32
16-1* Motor Status
16-10 Power [kW] 0.00 kW All set-ups TRUE 1 Int32
16-11 Power [hp] 0.00 hp All set-ups TRUE -2 Int32
16-12 Motor voltage 0.0 V All set-ups TRUE -1 Uint16
16-13 Frequency 0.0 Hz All set-ups TRUE -1 Uint16
16-14 Motor Current 0.00 A All set-ups TRUE -2 Int32
16-15 Frequency [%] 0.00 % All set-ups TRUE -2 N2
16-16 Torque [Nm] 0.0 Nm All set-ups TRUE -1 Int32
16-17 Speed [RPM] 0 RPM All set-ups TRUE 67 Int32
16-18 Motor Thermal 0 % All set-ups TRUE 0 Uint8
16-22
Torque [%] 0 % All set-ups TRUE 0 Int16
16-3* Drive Status
16-30 DC Link Voltage 0 V All set-ups TRUE 0 Uint16
16-32 Brake Energy /s 0.000 kW All set-ups TRUE 0 Uint32
16-33 Brake Energy /2 min 0.000 kW All set-ups TRUE 0 Uint32
16-34 Heatsink Temp. 0 °C All set-ups TRUE 100 Uint8
16-35 Inverter Thermal 0 % All set-ups TRUE 0 Uint8
16-36 Inv. Nom. Current ExpressionLimit All set-ups TRUE -2 Uint32
16-37 Inv. Max. Current ExpressionLimit All set-ups TRUE -2 Uint32
16-38 SL Controller State 0 N/A All set-ups TRUE 0 Uint8
16-39 Control Card Temp. 0 °C All set-ups TRUE 100 Uint8
16-40 Logging Buffer Full [0] No All set-ups TRUE - Uint8
16-5* Ref. & Feedb.
16-50 External Reference 0.0 N/A All set-ups TRUE -1 Int16
16-52 Feedback [Unit] 0.000 ProcessCtrlUnit All set-ups TRUE -3 Int32
16-53 Digi Pot Reference 0.00 N/A All set-ups TRUE -2 Int16
16-54 Feedback 1 [Unit] 0.000 ProcessCtrlUnit All set-ups TRUE -3 Int32
16-55 Feedback 2 [Unit] 0.000 ProcessCtrlUnit All set-ups TRUE -3 Int32
16-56 Feedback 3 [Unit] 0.000 ProcessCtrlUnit All set-ups TRUE -3 Int32
16-58 PID Output [%] 0.0 % All set-ups TRUE -1 Int16
16-59
Adjusted Setpoint 0.000 ProcessCtrlUnit All set-ups TRUE -3 Int32
16-6* Inputs & Outputs
16-60 Digital Input 0 N/A All set-ups TRUE 0 Uint16
16-61 Terminal 53 Switch Setting [0] Current All set-ups TRUE - Uint8
16-62 Analog Input 53 0.000 N/A All set-ups TRUE -3 Int32
16-63 Terminal 54 Switch Setting [0] Current All set-ups TRUE - Uint8
16-64 Analog Input 54 0.000 N/A All set-ups TRUE -3 Int32
16-65 Analog Output 42 [mA] 0.000 N/A All set-ups TRUE -3 Int16
16-66 Digital Output [bin] 0 N/A All set-ups TRUE 0 Int16
16-67 Pulse Input #29 [Hz] 0 N/A All set-ups TRUE 0 Int32
16-68 Pulse Input #33 [Hz] 0 N/A All set-ups TRUE 0 Int32
16-69 Pulse Output #27 [Hz] 0 N/A All set-ups TRUE 0 Int32
16-70 Pulse Output #29 [Hz] 0 N/A All set-ups TRUE 0 Int32
16-71 Relay Output [bin] 0 N/A All set-ups TRUE 0 Uint16
16-72 Counter A 0 N/A All set-ups TRUE 0 Int32
16-73 Counter B 0 N/A All set-ups TRUE 0 Int32
16-75 Analog In X30/11 0.000 N/A All set-ups TRUE -3 Int32
16-76 Analog In X30/12 0.000 N/A All set-ups TRUE -3 Int32
16-77 Analog Out X30/8 [mA] 0.000 N/A All set-ups TRUE -3 Int16
16-8* Fieldbus & FC Port
16-80 Fieldbus CTW 1 0 N/A All set-ups TRUE 0 V2
16-82 Fieldbus REF 1 0 N/A All set-ups TRUE 0 N2
16-84 Comm. Option Status 0 N/A All set-ups TRUE 0 V2
16-85 FC Port CTW 1 0 N/A All set-ups TRUE 0 V2
16-86
FC Port REF 1 0 N/A All set-ups TRUE 0 N2
16-9* Diagnosis Readouts
16-90 Alarm Word 0 N/A All set-ups TRUE 0 Uint32
16-91 Alarm word 2 0 N/A All set-ups TRUE 0 Uint32
16-92 Warning Word 0 N/A All set-ups TRUE 0 Uint32
16-93 Warning word 2 0 N/A All set-ups TRUE 0 Uint32
16-94 Ext. Status Word 0 N/A All set-ups TRUE 0 Uint32
16-95 Ext. Status Word 2 0 N/A All set-ups TRUE 0 Uint32
16-96 Maintenance Word 0 N/A All set-ups TRUE 0 Uint32
5 How to program the adjustable frequency
drive
VLT AQUA High Power Instruction Manual
5-60
MG.20.P3.22 - VLT
®
is a registered Danfoss trademark
5
