[21] Analog input X30-11 (General Purpose I/O Option Module)
[22] Analog input X30-12 (General Purpose I/O Option Module)
[29] Analog Input X48/2
3-16 Reference Resource 2
Option: Function:
Select the reference input to be used for the second reference signal. par. 3-15 Reference Resource
1
, par. 3-16 Reference Resource 2 and par. 3-17 Reference Resource 3 define up to three different
reference signals. The sum of these reference signals defines the actual reference.
[0] No function
[1] Analog input 53
[2] Analog input 54
[7] Frequency input 29
[8] Frequency input 33
[11] Local bus reference
[20] * Digital pot.meter
[21] Analog input X30-11
[22] Analog input X30-12
[29] Analog Input X48/2
3-17 Reference Resource 3
Option: Function:
Select the reference input to be used for the third reference signal. par. 3-15 Reference Resource
1
, par. 3-16 Reference Resource 2 and par. 3-17 Reference Resource 3 define up to three different
reference signals. The sum of these reference signals defines the actual reference.
[0] No function
[1] Analog input 53
[2] Analog input 54
[7] Frequency input 29
[8] Frequency input 33
[11] * Local bus reference
[20] Digital pot.meter
[21] Analog input X30-11
[22] Analog input X30-12
[29] Analog Input X48/2
VLT
®
AutomationDrive FC 300 Operating
Instructions
4 How to Programme
MG.33.AG.02 - VLT
®
is a registered Danfoss trademark 57
