4.3.3 5-3* Digital Outputs
Parameters for configuring the output functions for the output terminals. The 2 solid-state digital outputs are common for terminals 27 and 29. Set the
I/O function for terminal 27 in par. 5-01
Terminal 27 Mode , and set the I/O function for terminal 29 in par. 5-02 Terminal 29 Mode . These parameters
cannot be adjusted while the motor is running.
[0] No operation Default for all digital outputs and relay outputs
[1] Control ready The control card is ready. E.g.: Feedback from a drive where the control is supplied by an external
24 V (MCB107) and the main power to drive is not detected.
[2] Drive ready The frequency converter is ready for operation and applies a supply signal on the control board.
[3] Drive ready / remote control The frequency converter is ready for operation and is in Auto On mode.
[4] Enable / no warning Ready for operation. No start or stop command is been given (start/disable). No warnings are active.
[5] VLT running Motor is running and shaft torque present.
[6] Running / no warning Output speed is higher than the speed set in par. 1-81
Min Speed for Function at Stop [RPM] . The
motor is running and there are no warnings.
[7] Run in range / no warning Motor is running within the programmed current and speed ranges set in par. 4-50
Warning Current
Low
to par. 4-53 Warning Speed High . There are no warnings.
[8] Run on reference / no warning Motor runs at reference speed. No warnings.
[9] Alarm An alarm activates the output. There are no warnings.
[10] Alarm or warning An alarm or a warning activates the output.
[11] At torque limit The torque limit set in par. 4-16
Torque Limit Motor Mode or par. 4-17 has been exceeded.
[12] Out of current range The motor current is outside the range set in par. 4-18
Current Limit .
[13] Below current, low Motor current is lower than set in par. 4-50
Warning Current Low .
[14] Above current, high Motor current is higher than set in par. 4-51
Warning Current High .
[15] Out of range Output frequency is outside the frequency range set in par. 4-52
Warning Speed Low and
par. 4-53
Warning Speed High .
[16] Below speed, low Output speed is lower than the setting in par. 4-52
Warning Speed Low .
[17] Above speed, high Output speed is higher than the setting in par. 4-53
Warning Speed High .
[18] Out of feedback range Feedback is outside the range set in par. 4-56
Warning Feedback Low and par. 4-57 Warning Feed-
back High
.
[19] Below feedback low Feedback is below the limit set in par. 4-56
Warning Feedback Low .
[20] Above feedback high Feedback is above the limit set in par. 4-57
Warning Feedback High .
[21] Thermal warning The thermal warning turns on when the temperature exceeds the limit in the motor, the frequency
converter, the brake resistor, or the thermistor.
[22] Ready, no thermal warning Frequency converter is ready for operation and there is no over-temperature warning.
[23] Remote, ready, no thermal warning Frequency converter is ready for operation and is in Auto On mode. There is no over-temperature
warning.
[24] Ready, no over-/ under voltage Frequency converter is ready for operation and the mains voltage is within the specified voltage
range (see
General Specifications section in the Designn Guide).
[25] Reverse
Reversing. Logic ‘1’ when CW rotation of the motor. Logic ‘0’ when CCW rotation of the motor. If
the motor is not rotating the output will follow the reference.
[26] Bus OK Active communication (no time-out) via the serial communication port.
[27] Torque limit and stop Use in performing a coasting stop and in torque limit condition. If the frequency converter has
received a stop signal and is at the torque limit, the signal is Logic ‘0’.
[28] Brake, no brake warning Brake is active and there are no warnings.
[29] Brake ready, no fault Brake is ready for operation and there are no faults.
[30] Brake fault (IGBT) Output is Logic ‘1’ when the brake IGBT is short-circuited. Use this function to protect the frequency
converter if there is a fault on the brake modules. Use the output/relay to cut out the main voltage
from the frequency converter.
[31] Relay 123 Relay is activated when Control Word [0] is selected in parameter group 8-**.
VLT
®
AutomationDrive FC 300 Operating
Instructions
4 How to Programme
MG.33.AG.02 - VLT
®
is a registered Danfoss trademark 63
