Danfoss VLT AutomationDrive FC 302

4
e30bg420.10
5
2
1
3
6
1 Screwdriver access holes for captive screws (T25) 4 Nut (T25)
2 Threaded stud 5 Telescoping duct
3 Duct ange 6 Heat sink fan cover
Illustration 10.23 Heat Sink Fan Access with Telescoping Cooling Duct
D1h/D3h/D5h/D6h/J8 Drive Di... Service Guide
MG94A502 Danfoss A/S © 02/2019 All rights reserved. 171
10 10
