Danfoss VLT AutomationDrive FC 302 Service Guide

1
2
3
4
6
9
10
7
8
5
e30bg396.10
1 Captive screws (T25) 6 Heat sink fan
2 Mounting studs 7 Heat sink fan cable connector
3 Hole for cable grommet 8 Cable grommet
4 Slots for heat sink fan cover 9 Heat sink fan cover
5 Mounting holes 10 Fan cover tabs
Illustration 10.24 Heat Sink Fan in IP21/IP54 (UL type 1/12) Drives
D1h/D3h/D5h/D6h/J8 Drive Di...
VLT
®
FC Series, D1h–D8h, Da2/Db2/Da4/Db4, E1h–E4h, J8/J9
172 Danfoss A/S © 02/2019 All rights reserved. MG94A502
