Danfoss VLT AutomationDrive FC 302 Installation Manual

Par.
No. #
Parameter description Default value 4-set-up FC 302
only
Change
during
operation
Conver-
sion index
Type
15-76 Option in Slot C1 0 N/A All set-ups FALSE 0 VisStr[30]
15-77 Slot C1 Option SW Version 0 N/A All set-ups FALSE 0 VisStr[20]
15-9* Parameter Info
15-92 Dened Parameters 0 N/A All set-ups FALSE 0 Uint16
15-93 Modied Parameters 0 N/A All set-ups FALSE 0 Uint16
15-98 Unit Identication 0 N/A All set-ups FALSE 0 VisStr[40]
15-99 Parameter Metadata 0 N/A All set-ups FALSE 0 Uint16
9.3.7 Data Readouts 16-**
Par.
No. #
Parameter description Default value 4-set-up FC 302
only
Change
during
operation
Conver-
sion
index
Type
16-0* General Status
16-00 Control Word 0 N/A All set-ups FALSE 0 V2
16-03 Status Word 0 N/A All set-ups FALSE 0 V2
16-3* AF Status
16-30 DC Link Voltage 0 V All set-ups FALSE 0 Uint16
16-34 Heatsink Temp. 32°F [0°C] All set-ups FALSE 100 Uint8
16-35 Inverter Thermal 0% All set-ups FALSE 0 Uint8
16-36 Inv. Nom. Current ExpressionLimit All set-ups FALSE -2 Uint32
16-37 Inv. Max. Current ExpressionLimit All set-ups FALSE -2 Uint32
16-39 Control Card Temp. 32°F [0°C] All set-ups FALSE 100 Uint8
16-40 Logging Buer Full [0] No All set-ups TRUE - Uint8
16-49 Current Fault Source 0 N/A All set-ups TRUE 0 Uint8
16-6* Inputs & Outputs
16-60 Digital Input 0 N/A All set-ups FALSE 0 Uint16
16-66 Digital Output [bin] 0 N/A All set-ups FALSE 0 Int16
16-71 Relay Output [bin] 0 N/A All set-ups FALSE 0 Int16
16-8* & FC Port
16-80 CTW 1 0 N/A All set-ups FALSE 0 V2
16-84 Comm. Option STW 0 N/A All set-ups FALSE 0 V2
16-85 FC Port CTW 1 0 N/A All set-ups FALSE 0 V2
16-9* Diagnosis Readouts
16-90 Alarm Word 0 N/A All set-ups FALSE 0 Uint32
16-91 Alarm Word 2 0 N/A All set-ups FALSE 0 Uint32
16-92 Warning Word 0 N/A All set-ups FALSE 0 Uint32
16-93 Warning Word 2 0 N/A All set-ups FALSE 0 Uint32
16-94 Ext. Status Word 0 N/A All set-ups FALSE 0 Uint32
Appendix A - Parameters Installation Manual
MG37A322 Danfoss A/S © Rev. 04/2015 All rights reserved. 117
