9.3.8 AF Settings 300-**
NOTICE!
Except for parameter 300-10 Active Filter Nominal Voltage, it is not recommended to change the settings in this par.
group for the Low Harmonic Drive
Par. No. # Parameter description Default value 4-set-up FC 302
only
Change
during
operation
Conver-
sion
index
Type
300-0* General Settings
300-00 Harmonic Cancellation Mode [0] Overall All set-ups TRUE - Uint8
300-01 Compensation Priority [0] Harmonics All set-ups TRUE - Uint8
300-1* Network Settings
300-10 Active Filter Nominal Voltage ExpressionLimit 2 set-ups FALSE 0 Uint32
300-2* CT Settings
300-20 CT Primary Rating ExpressionLimit 2 set-ups FALSE 0 Uint32
300-22 CT Nominal Voltage 342 V 2 set-ups FALSE 0 Uint32
300-24 CT Sequence [0] L1, L2, L3 2 set-ups FALSE - Uint8
300-25 CT Polarity [0] Normal 2 set-ups FALSE - Uint8
300-26 CT Placement [1] Load Current 2 set-ups FALSE - Uint8
300-29 Start Auto CT Detection [0] O All set-ups FALSE - Uint8
300-3* Compensation
300-30 Compensation Points 0.0 A All set-ups TRUE -1 Uint32
300-35 Cos-phi Reference 0.500 N/A All set-ups TRUE -3 Uint16
300-4* Paralleling
300-40 Master Follower Selection [2] Not Paralleled 2 set-ups FALSE - Uint8
300-41 Follower ID 1 N/A 2 set-ups FALSE 0 Uint32
300-42 Num. of Follower AFs 1 N/A 2 set-ups FALSE 0 Uint32
300-5* Sleep Mode
300-50 Enable Sleep Mode null 2 set-ups TRUE - Uint8
300-51 Sleep Mode Trig Source [0] Line power All set-ups TRUE - Uint8
300-52 Sleep Mode Wake-up Trigger ExpressionLimit All set-ups TRUE 0 Uint32
300-53 Sleep Mode Sleep Trigger 80% All set-ups TRUE 0 Uint32
Appendix A - Parameters
VLT
®
AutomationDrive FC 302 Low Harmonic Drive
132–630 kW
118 Danfoss A/S © Rev. 04/2015 All rights reserved. MG37A322
