Danfoss VLT AutomationDrive FC 302

130BX334.11
2
3
4
5
6
1
1 Contactor 4 Circuit breaker or disconnect (if purchased)
2 RFI lter 5 AC line power/line fuses (if purchased)
3 Line power AC power input terminals
Figure 1.6 Frame Size F18 Options Cabinet
*The options cabinet is not optional for the LHD. The ancillary equipment is stored in the cabinet.
