9 Basic Troubleshooting
9.1 Start Up and Operation
See Alarm Log in Table 4.1.
Symptom Possible Cause Test Solution
Display dark / No function
Missing input power
See Table 3.1.
Check the input power source.
Missing or open fuses or circuit
breaker tripped
See open fuses and tripped circuit
breaker in this table for possible
causes.
Follow the recommendations
provided
No power to the LCP Check the LCP cable for proper
connection or damage.
Replace the faulty LCP or
connection cable.
Shortcut on control voltage
(terminal 12 or 50) or at control
terminals
Check the 24V control voltage
supply for terminal 12/13 to 20-39
or 10V supply for terminal 50 to 55.
Wire the terminals properly.
Wrong LCP (LCP from VLT
®
2800
or 5000/6000/8000/ FCD or FCM)
Use only LCP 101 (P/N 130B1124)
or LCP 102 (P/N. 130B1107).
Wrong contrast setting Press [Status] + Up/Down arrows
to adjust the contrast.
Display (LCP) is defective Test using a different LCP. Replace the faulty LCP or
connection cable.
Internal voltage supply fault or
SMPS is defective
Contact supplier.
Intermittent display
Overloaded power supply (SMPS)
due to improper control wiring or
a fault within the Adjustable
frequency drive
To rule out a problem in the
control wiring, disconnect all
control wiring by removing the
terminal blocks.
If the display stays lit, then the
problem is in the control wiring.
Check the wiring for shorts or
incorrect connections. If the display
continues to cut out, follow the
procedure for display dark.
Basic Troubleshooting
VLT
®
AutomationDrive Instruction
Manual
MG.33.AI.22 - VLT
®
is a registered Danfoss trademark 9-1
9
9
