7.13.3 Immunity Requirements
The immunity requirements for drives depend on the installation environment. The requirements for the industrial
environment are higher than the requirements for the home and oce environment. All Danfoss drives comply with the
requirements for both the industrial and the home/oce environment.
To document immunity against burst transient, the following immunity tests have been performed on a drive (with options
if relevant), a shielded control cable, and a control box with potentiometer, motor cable, and motor. The tests were
performed in accordance with the following basic standards. For more details, see Table 7.17.
•
EN 61000-4-2 (IEC 61000-4-2): Electrostatic discharges (ESD): Simulation of electrostatic discharges from human
beings.
•
EN 61000-4-3 (IEC 61000-4-3): Incoming electromagnetic
eld radiation, amplitude modulated simulation of the
eects of radar, radio communication equipment, and mobile communications equipment.
•
EN 61000-4-4 (IEC 61000-4-4): Burst transients: Simulation of interference brought about by switching a contactor,
relay, or similar devices.
•
EN 61000-4-5 (IEC 61000-4-5): Surge transients: Simulation of transients brought about by lightning strikes near
installations.
•
EN 61000-4-6 (IEC 61000-4-6): RF common mode: Simulation of the eect from radio-transmission equipment
joined by connection cables.
Basic standard Burst
IEC 61000-4-4
Surge
IEC 61000-4-5
ESD
IEC
61000-4-2
Radiated
electro-magnetic eld
IEC 61000-4-3
RF common
mode voltage
IEC 61000-4-6
Acceptance criterion B B B A A
Line 4 kV CM
2 kV/2 Ω DM
4 kV/12 Ω CM
– – 10 V
RMS
Motor 4 kV CM
4 kV/2 Ω
1)
– – 10 V
RMS
Control wires 2 kV CM
2 kV/2 Ω
1)
– – 10 V
RMS
Standard bus 2 kV CM
2 kV/2 Ω
1)
– – 10 V
RMS
Relay wires 2 kV CM
2 kV/2 Ω
1)
– – 10 V
RMS
Application/eldbus options 2 kV CM
2 kV/2 Ω
1)
– – 10 V
RMS
LCP cable 2 kV CM
2 kV/2 Ω
1)
– – 10 V
RMS
External 24 V DC 2 V CM
0.5 kV/2 Ω DM
1 kV/12 Ω CM
– – 10 V
RMS
Enclosure – – 8 kV AD
6 kV CD
10 V/m –
Table 7.17 EMC Immunity Form, Voltage Range: 380–480
1) Injection on cable shield.
AD: air discharge; CD: contact discharge; CM: common mode; DM:
dierential mode.
Electrical Installation Con... Design Guide
MG06K102 Danfoss A/S © 03/2019 All rights reserved. 53
7 7
