Coil number Description Signal direction
1–16 Drive control word (see Table 11.14). Master-to-slave
17–32 Drive speed or setpoint reference range 0x0–0xFFFF (-200% ... ~200%). Master-to-slave
33–48 Drive status word (see Table 11.14). Master-to-slave
49–64 Open-loop mode: Drive output frequency.
Closed-loop mode: Drive feedback signal.
Slave-to-master
65 Parameter write control (master-to-slave).
Master-to-slave
0 = Parameter changes are written to the RAM of the drive.
1 = Parameter changes are written to the RAM and EEPROM of the drive.
66–65536 Reserved.
Table 11.13 Coils and Holding Registers
Coil 0 1
01 Preset reference LSB
02 Preset reference MSB
03 DC brake No DC brake
04 Coast stop No coast stop
05 Quick stop No quick stop
06 Freeze frequency No freeze frequency
07 Ramp stop Start
08 No reset Reset
09 No jog Jog
10 Ramp 1 Ramp 2
11 Data not valid Data valid
12 Relay 1 o Relay 1 on
13 Relay 2 o Relay 2 on
14 Set up LSB
15 Set up MSB
16 No reversing Reversing
Table 11.14 Drive Control Word (FC Prole)
Coil 0 1
33 Control not ready Control ready
34 Drive not ready Drive ready
35 Coasting stop Safety closed
36 No alarm Alarm
37 Not used Not used
38 Not used Not used
39 Not used Not used
40 No warning Warning
41 Not at reference At reference
42 Hand mode Auto mode
43 Out of frequency range In frequency range
44 Stopped Running
45 Not used Not used
46 No voltage warning Voltage warning
47 Not in current limit Current limit
48 No thermal warning Thermal warning
Table 11.15 Drive Status Word (FC Prole)
Register
number
Description
00001–00006 Reserved.
00007 Last fault code from an FC data object interface.
00008 Reserved.
00009
Parameter index
1)
.
00010–00990 000 parameter group (parameters 001–099).
01000–01990 100 parameter group (parameters 100–199).
02000–02990 200 parameter group (parameters 200–299).
03000–03990 300 parameter group (parameters 300–399).
04000–04990 400 parameter group (parameters 400–499).
... ...
49000–49990 4900 parameter group (parameters 4900–4999).
50000 Input data: Drive control word register (CTW).
50010 Input data: Bus reference register (REF).
... ...
50200 Output data: Drive status word register (STW).
50210 Output data: Drive main actual value register (MAV).
Table 11.16 Holding Registers
1) Used to specify the index number used when accessing an indexed parameter.
Appendix VLT® AutomationDrive FC 361
86 Danfoss A/S © 03/2019 All rights reserved. MG06K102
