frequency converter is no longer blocked and can be reset

once the cause has been rectied.

Alarms that are not trip locked can also be reset using the

automatic reset function in parameter 14-20 Reset Mode

(Warning: Automatic wake-up is possible.)

If a warning or alarm is marked against a code in Table 6.4,

this means that either a warning occurs before an alarm, or

it is possible to specify whether a warning or an alarm

should be shown for a given fault.

This is possible, for instance, in parameter 1-90 Motor

Thermal Protection. After an alarm or trip, the motor carries

on coasting, and the alarm and warning ash. Once the

problem has been rectied, only the alarm continues

ashing until the frequency converter is reset.

NOTICE

No missing motor phase detection (numbers 30-32) and

no stall detection are active when parameter 1-10 Motor

Construction is set to [1] PM non-salient SPM.

Number Description Warning Alarm/

Trip

Alarm/

Trip Lock

Parameter

Reference

1 10 volts low X – –

2 Live zero error (X) (X) – Parameter 6-01 Live Zero Timeout Function

3 No motor (X) – – Parameter 1-80 Function at Stop

4 Mains phase loss (X) (X) (X) Parameter 14-12 Response to Mains

Imbalance

5 DC-link voltage high X – – –

6 DC-link voltage low X – – –

7 DC overvoltage X X – –

8 DC undervoltage X X – –

9 Inverter overloaded X X – –

10 Motor ETR overtemperature (X) (X) – Parameter 1-90 Motor Thermal Protection

11 Motor thermistor overtemperature (X) (X) – Parameter 1-90 Motor Thermal Protection

12 Torque limit X X – –

13 Overcurrent X X X –

14 Ground fault X X – –

15 Hardware mismatch – X X –

16 Short circuit – X X –

17 Control word timeout (X) (X) – Parameter 8-04 Control Word Timeout

Function

20 Temp. input error – X – –

21 Param error – X –

22 Hoist mech. brake (X) (X) – Parameter group 2-2* Mechanical Brake

23 Internal fans X – – –

24 External fans X – – –

25 Brake resistor short-circuited X – – –

26 Brake resistor power limit (X) (X) – Parameter 2-13 Brake Power Monitoring

27 Brake chopper short-circuited X X –

28 Brake check (X) (X) – Parameter 2-15 Brake Check

29 Heat sink temp X X X

30 Motor phase U missing (X) (X) (X) Parameter 4-58 Missing Motor Phase Function

31 Motor phase V missing (X) (X) (X) Parameter 4-58 Missing Motor Phase Function

32 Motor phase W missing (X) (X) (X) Parameter 4-58 Missing Motor Phase Function

33 Inrush fault X X –

34 Fieldbus communication fault X X – –

35 Option fault – – X –

36 Mains failure X X – –

37 Imbalance of supply voltage X – –

38 Internal fault X X –
