Number Description Warning Alarm/

Trip

Alarm/

Trip Lock

Parameter

Reference

39 Heat sink sensor X X –

40 Overload of digital output terminal 27 (X) – – Parameter 5-00 Digital I/O Mode,

parameter 5-01 Terminal 27 Mode

41 Overload of digital output terminal 29 (X) – – Parameter 5-00 Digital I/O Mode,

parameter 5-02 Terminal 29 Mode

42 Ovrld X30/6-7 (X) – – –

43 Ext. supply (option) X – – –

45 Ground fault 2 X X – –

46 Pwr. card supply – X X –

47 24 V supply low X X X –

48 1.8 V supply low – X X –

49 Speed limit – X – Parameter 1-86 Trip Speed Low [RPM]

50 AMA calibration failed – X – –

51 AMA check U

nom

and I

nom

– X – –

52 AMA low I

nom

– X – –

53 AMA motor too big – X – –

54 AMA motor too small – X – –

55 AMA parameter out of range – X – –

56 AMA interrupted by user – X – –

57 AMA time-out – X – –

58 AMA internal fault X X – –

59 Current limit X – –

60 External interlock X X – –

61 Feedback error (X) (X) – Parameter 4-30 Motor Feedback Loss Function

62 Output frequency at maximum limit X – –

63 Mechanical brake low (X) – Parameter 2-20 Release Brake Current

64 Voltage limit X – – –

65 Control board overtemperature X X X –

66 Heat sink temperature low X – –

67 Option conguration has changed – X – –

68 Safe stop (X)

(X)

– Parameter 5-19 Terminal 37 Safe Stop

69 Pwr. card temp – X X –

70 Illegal FC conguration – – X –

71 PTC 1 Safe Stop – X – –

72 Dangerous failure – X –

73 Safe Stop Auto Restart (X) (X) – Parameter 5-19 Terminal 37 Safe Stop

74 PTC Thermistor – – X –

75 Illegal Prole Sel. – X – –

76 Power unit setup X – – –

77 Reduced power mode X – – Parameter 14-59 Actual Number of Inverter

Units

78 Tracking error (X) (X) – Parameter 4-34 Tracking Error Function

79 Illegal PS cong – X X

80 Frequency converter Initialized to default value – X – –

81 CSIV corrupt – X – –

82 CSIV parameter error – X – –

83 Illegal option combination – – X –

84 No safety option – X – –

88 Option detection – – X –

89 Mechanical brake sliding X – – –

90 Feedback monitor (X) (X) – Parameter 17-61 Feedback Signal Monitoring
