[7] Pulse input 29
[8] Pulse input 33
[20] Digital pot.meter
[21] Analog input X30/11
[22] Analog input X30/12
[23] Analog Input X42/1
[24] Analog Input X42/3
[25] Analog Input X42/5
[30] Ext. Closed Loop 1
[31] Ext. Closed Loop 2
[32] Ext. Closed Loop 3
3-16 Reference 2 Source
Option: Function:
Select the reference input to be used for the second reference signal. par. 3-15
Reference 1
Source
, par. 3-16
Reference 2 Source
and par. 3-17
Reference 3 Source
define up to three different
reference signals. The sum of these reference signals defines the actual reference.
This parameter cannot be adjusted while the motor is running.
[0] No function
[1] Analog input 53
[2] Analog input 54
[7] Pulse input 29
[8] Pulse input 33
[20] * Digital pot.meter
[21] Analog input X30/11
[22] Analog input X30/12
[23] Analog Input X42/1
[24] Analog Input X42/3
[25] Analog Input X42/5
[30] Ext. Closed Loop 1
[31] Ext. Closed Loop 2
[32] Ext. Closed Loop 3
4-10 Motor Speed Direction
Option: Function:
Selects the motor speed direction required.
Use this parameter to prevent unwanted reversing.
[0] Clockwise Only operation in clockwise direction will be allowed.
[2] * Both directions Operation in both clockwise and anti-clockwise direction will be allowed.
NB!
The setting in par. 4-10
Motor Speed Direction
has impact on the Flying Start in par. 1-73
Flying Start
.
