6.3.22 24-** Application Functions 2
Par.
No. #
Parameter description Default value 4-set-up Change dur-
ing operation
Conver-
sion index
Type
24-0* Fire Mode
24-00 Fire Mode Function [0] Disabled 2 set-ups TRUE - Uint8
24-01 Fire Mode Configuration [0] Open Loop All set-ups TRUE - Uint8
24-02 Fire Mode Unit null All set-ups TRUE - Uint8
24-03 Fire Mode Min Reference SR All set-ups TRUE -3 Int32
24-04 Fire Mode Max Reference SR All set-ups TRUE -3 Int32
24-05 Fire Mode Preset Reference 0.00 % All set-ups TRUE -2 Int16
24-06 Fire Mode Reference Source [0] No function All set-ups TRUE - Uint8
24-07 Fire Mode Feedback Source [0] No function All set-ups TRUE - Uint8
24-09 Fire Mode Alarm Handling [1] Trip, Critical Alarms 2 set-ups FALSE - Uint8
24-1* Drive Bypass
24-10 Drive Bypass Function [0] Disabled 2 set-ups TRUE - Uint8
24-11 Drive Bypass Delay Time 0 s 2 set-ups TRUE 0 Uint16
24-9* Multi-Motor Funct.
24-90 Missing Motor Function [0] Off All set-ups TRUE - Uint8
24-91 Missing Motor Coefficient 1 0.0000 N/A All set-ups TRUE -4 Int32
24-92 Missing Motor Coefficient 2 0.0000 N/A All set-ups TRUE -4 Int32
24-93 Missing Motor Coefficient 3 0.0000 N/A All set-ups TRUE -4 Int32
24-94 Missing Motor Coefficient 4 0.000 N/A All set-ups TRUE -3 Int32
24-95 Locked Rotor Function [0] Off All set-ups TRUE - Uint8
24-96 Locked Rotor Coefficient 1 0.0000 N/A All set-ups TRUE -4 Int32
24-97 Locked Rotor Coefficient 2 0.0000 N/A All set-ups TRUE -4 Int32
24-98 Locked Rotor Coefficient 3 0.0000 N/A All set-ups TRUE -4 Int32
24-99 Locked Rotor Coefficient 4 0.000 N/A All set-ups TRUE -3 Int32
VLT HVAC Low Harmonic Drive Operating In-
structions 6 How to Programme the Low Harmonic Drive
MG.16.A1.02 - VLT
®
is a registered Danfoss trademark 143
