4 How to Install
4.1 How to Get Started
4.1.1 About How to Install
This chapter covers mechanical and electrical installations to and from power terminals and control card terminals.
Electrical installation of
options
is described in the relevant Operating Instructions and Design Guide.
4.1.2 How to Get Started
The frequency converter is designed to achieve a quick and EMC-correct installation by following the steps described below.
Read the safety instructions before installing the unit.
Failure to follow recommendations could result in death or serious injury.
Mechanical Installation
• Mechanical mounting
Electrical Installation
• Connection to Mains and Protecting Earth
• Motor connection and cables
• Fuses and circuit breakers
• Control terminals - cables
Quick Setup
• Local Control Panel (LCP) of frequency converter
• Local Control Panel of filter
• Automatic Motor Adaptation, AMA
• Programming
Frame size is depending on enclosure type, power range and mains volt-
age
Illustration 4.1: Diagram showing basic installation including
mains, motor, start/stop key, and potentiometer for speed
adjustment.
VLT HVAC Low Harmonic Drive Operating In-
structions
4 How to Install
MG.16.A1.02 - VLT
®
is a registered Danfoss trademark 15
4
To Next Page
