3706 (145.9)
2202 (86.7)
1496 (58.9)
2277 (89.7)
Ø29 (1.1)
Ø40 (1.6)
605 (23.8)
225 (8.9)
130BB422.10
Illustration 4.7: Frame size F17, front and side view
