8.1.14 Wiring Conguration for a Compressor Pack
P
0
e30ba807.10
Illustration 64: P
0
Pressure Transmitter
AC Drive
Supply
1 2
AKS33
12 18 27 20 37 55 54 U V W
e30ba808.12
Illustration 65: How to Connect the FC 103 and AKS33 for Closed-Loop Applications
N O T I C E
To nd out which parameters are relevant, run the SmartStart.
