Character position
Code
Description
M
Mains bottom, motor top
Table 17: Auxiliary Power Supply Codes
Character position
Code
Description
21
1
230 V AC external
2
230 V AC internal
4
230 V AC internal + 24 V DC internal
5
230 V AC external + 24 V DC internal
6
120 V AC external
7
120 V AC internal
8
120 V AC internal + 24 V DC internal
9
120 V AC external + 24 V DC internal
Table 18: Back-channel Cooling Codes
Character position
Code
Description
22
X
Bottom in, top out
1
Back in, back out
C
Back in, top out
D
Bottom in, back out
N
None
Table 19: Auxiliary Function Codes
Character posi-
tion
Code
Description
23–24
AX
No auxiliary options
A1
AC socket+cabinet light
A2
Extended I/O terminals
A3
Cabinet heater
A4
Motor heater control
A5
Insulation monitor
AA
AC socket + cabinet light + extended I/O terminals
AB
AC socket + cabinet light + cabinet heater
AC
AC socket + cabinet light + motor heater control
AD
AC socket + cabinet light + insulation monitor
AE
AC socket + cabinet light + extended I/O terminals + cabinet heater
